Local Display
|
Liv eView Display
8 Channels
Multi-Lay out Display : 1x1, 2x2, 3x3, 1M+5, 1P+3, 1P+6, 2P+3, 3V
Video Output HDMI x1, VGA x1
Display Resolution 3840x2160, 1920x1080, 1280x720
Stream Application Constant\Auto Stream
Fishey e Dewarp Web dewarp 1O, 1P, 1R
PTZ Operation Direction Control, Home, Iris, Preset, Patrol (Group), PiP Control
|
|
Video
|
Video Format H.265, H.264, MJPEG
Graphic Decoder Hardware decoding
Decoding Resolution Up to 3840x2160
Decoding Capability
3840x2160 @ 30 f ps (1-CH)
1920x1080 @ 120 f ps (4-CH)
1280x720 @ 240 f ps (8-CH)
|
|
Audio
|
Audio Format G.711, G.726
Audio In/Out
3.5 Phone jack audio output x1
3.5 Phone jack audio input (reserv ed) x1
Record
Recording Time (sec.)
Pre-Record: 5 (Max. 10)
Post-Record: 20 (Max. 300)
Recording Stream Single
Recording Throughput 64 Mbps
Recording Mode Continuous, Schedule, Manual, Ev ent
Recording Setting Recy cle (unit: Day )
Watermark Supported
|
|
Storage & Backup
|
HDD Dev ices
Internal x2 (3.5")
*HDD is purchased by separately.
HDD Max. Capacity *Please ref er to the HDD supported list on the VIVOTEK website.
RAID RAID 0, 1 (single v olume up to 16TB)
Disk Management Create, Format and Remov e Disk
HDD S.M.A.R.T.
External Storage USB Storage (USB 3.0)
Video Clip Export USB Dongle (FAT Format)
Schedule Backup FTP
|
|
Playback
|
Play back Display
4 Channels
Multi-Lay out Display : 1x1, 2x2, 1P+3, 1V+3
Play back Control Regular (play, pause, stop), rewind, next/prev ious f rame, speed control, calendar,
ev ent, timeline, timeline scale, thumbnail (story board)
Video Search By calendar, date/time, and alarm
Thumbnail Explorer (Story board) Listing the thumbnail of recorded v ideo (Max. 2-CH)
Snapshot JPEG
Video Clip Export EXE
|
|
Network
|
Ethernet 10/100/1000Mbps Ethernet (RJ-45) x1
Network Throughput Input/Output Total 88 Mbps
|
|
PoE
|
802.3at/af compliant PoE ports x 8 (Total Max. 120 W)
* DO NOT suggest connecting any non-PD dev ice with this NVR PoE port in order to
av oid potential risk.
PoE Management Supported
Protocols
IPv 4, IPv 6, TCP/IP, HTTP, HTTPS, UPnP, RTSP/RTP/RTCP, SMTP, FTP, DHCP, NTP,
DNS, DDNS, IP Filter
External Interface
|
|
USB
|
Front: 1 (USB 3.0)
Back: 1 (USB 2.0)
Alarm In 4
Alarm Out 1
|
|
Audio
|
3.5 Phone Jack Audio Output x1
3.5 Phone Jack Audio Input (Reserv ed) x1
|
|
System
|
Camera Integration ONVIF Prof ile S
Ev ent Motion Detection, Smart VCA Ev ent, PIR Detection, Tampering Detection, Camera
DI/DO, Camera Disconnected, Disk Failure, Disk Full, NVR DI/DO, PoE error
Ev ent Action
Video recording, email with snapshot, buzzer, PTZ, FTP, DO (camera, sy stem), f ull
screen, send to CMS, VIVOCloud APP Notif ication
User Management User lev el: administrator, regular user
Log Sy stem, recording, user, error
Date & Time Time Zone, Manual, Automatic Sy nc NTP, Day light Sav ing Time
Language Czech, English, French, German, Italian, Japanese, Korean, Portuguese, Polish,
Russian, Spanish, Simplif ied Chinese, Traditional Chinese, Arabic
|
|
Advanced Features
|
VCA Counting Solution Supported
VCA Ev ent Search Supported
|
|
Remote Client
|
Sof tware AP Shepherd, VAST 2
Mobile/Tablet App iViewer (Android & iOS)
Web Browser
Internet Explorer 10 (32 bit) or later/ Windows
Chrome v 68.0.3 or later/ Windows f or new web
VIVOCloud Supported
|
|
General
|
Power Input 100-240V AC, 50/60Hz
Power Consumption Max. 175 W
Dimensions 366 (W) x 320.3 (D) x 46 (H)mm
Weight 2.5 kg (without HDD)
Operating Temperature 0°C ~ 40°C (32°F ~ 104°F)
Humidity 0 ~ 95%
Saf ety Certif ications CE, FCC, VCCI, C-Tick, UL, CB, BSMI, BIS
Warranty 36 months
|
