HARDWARE FEATURES

Memory
1 GB RAM and 128 MB Flash
Interface
8 1G/100M/10M LAN Ports,
1 2.5G/2G/1G/100M WAN Port
1 USB-A 3.0 Port + 1 USB-C 3.0 Port
Button
Wi-Fi On/Off Button, Reset Button, WPS Button, Power On/Off Button, LED on/off Button
External Power Supply
12V/4A
Dimensions
( W x D x H )
10.3×10.3×2.4in (261.2×261.2×60.2mm)
Antenna
8 High-Performance External Antennas

WIRELESS FEATURES

Wireless Standards
IEEE 802.11ax/ac/n/a 5GHz
IEEE 802.11ax/n/b/g 2.4GHz
Frequency
2.4GHz and 5GHz
Signal Rate
5GHz: 4804Mbps(802.11ax)
2.4GHz: 1148Mbps(802.11ax)
compatible with 802.11a/b/g/n/ac Wi-Fi standards
Reception Sensitivity
5GHz: 11a 6Mbps:-97dBm, 11a 54Mbps:-79dBm -11ac VHT20_MCS0:-96dBm, 11ac VHT20_MCS11:-66dBm -11ac VHT40_MCS0:-94dBm,
11ac VHT40_MCS11:-63dBm - 11ac VHT80_MCS0:-91dBm, 11ac VHT80_MCS11:-60dBm - 11ac VHT160_MCS0:-88dBm, 11ac
VHT160_MCS11:-55dBm - 11ax HE20_MCS0:-95dBm, 11ax HE20_MCS11:-63dBm - 11ax HE40_MCS0:-92dBm, 11ax HE40_MCS11:-60dBm
<11ax HE80_MCS0:-89dBm, 11ax HE80_MCS11:-58dBm -11ax HE160_MCS0:-85dBm, 11ax HE160_MCS11:-55dBm - 2.4GHz:- 11g
6Mbps:-97dBm, 11a 54Mbps:-79dBm - 11n HT20_MCS0:-97dBm, 11n HT20_MCS7:-78dBm - 11n HT40_MCS0:-95dBm, 11n HT40_MCS7:-75dBm
11ac VHT20_MCS0:-96dBm, 11ac VHT20_MCS11:-67dBm - 11ac VHT40_MCS0:-94dBm, 11ac VHT40_MCS11:-64dBm - 11ax - HE20_MCS0:-96dBm, 11ax HE20_MCS11:-64dBm -11ax HE40_MCS0:-93dBm, 11ax HE40_MCS11:-61dBm
Wireless Functions Enable/Disable Wireless Radio, Guest network, DFS, MU-MIMIO, OFDMA

Wireless Security
64/128-bit WEP, WPA/WPA2, WPA-PSK/WPA2-PSK encryptions
Transmission Power
CE: <20dBm(2.4GHz), <23dBm(5.15GHz~5.35GHz); <30dBm(5.47GHz~5.725GHz)
FCC: <30dBm(2.4GHz &
5.15GHz~5.25GHz & 5.725GHz~5.825GHz)
Guest Network
2.4GHz guest network x 1, 5GHz guest network x 1

SOFTWARE FEATURES

Quality of Service
Advanced Qos powered by TrendMicro
WAN Type
Dynamic IP/Static IP/PPPoE/
PPTP(Dual Access)/L2TP(Dual Access)
Management
Advanced Parental control powered by TrendMicro, Local Management, Remote Management
DHCP
Server, DHCP Client List, Address Reservation
Port Forwarding
Virtual Server, Port Triggering, UPnP, DMZ
Dynamic DNS
DynDns, NO-IP, TP-Link
VPN Server
PPTP, OpenVPN
