Intel i7-13700F 2.10G 30MB SKT 1700 16C

Product Description

Intel Core i7-13700F 2.1 GHz 16-Core LGA 1700 Processor. This 13th generation desktop processor builds upon the Hybrid Core architecture and Intel 7 process by fitting 16 cores— four more than the previous generation— onto a single processor while still supporting the LGA 1700 socket. Designed to provide high performance, the Core i7-13700F features eight low-voltage Efficient-cores that handle background tasks for multitasking while the eight 2.1 GHz Performance-cores provide speed for demanding applications and games. The built-in Intel Thread Director ensures that the two work seamlessly together by dynamically and intelligently assigning workloads to the right core at the right time.

With 30MB of cache and a 5.2 GHz Turbo Boost Max 3.0 frequency, this processor is made to handle intense workloads. The Core i7-13700F also supports PCI Express 5.0 and dual-channel DDR5 memory at 5600 MHz.

The Core i7-13700K does not include integrated graphics, meaning that users will need to purchase a separate dedicated graphics card. Please note that a thermal solution is NOT included. This processor is backed by a 3-year warranty.

Hybrid Core Design
Performance-cores provide the speed to handle high-end games and demanding applications while low-priority and background tasks are handled by the processor's Efficient-cores for multitasking.
Intel Thread Director
The Intel Thread Director is built into the CPU's cores, working with the operating system to ensure each of the 24 threads are assigned to the right core at the right time.
PCIe 4.0 & 5.0
This processor supports up to four PCIe 4.0 and sixteen PCIe 5.0 lanes, delivering 20 lanes in total for exceptional data throughput with compatible devices.
Gaussian & Neural Accelerator 3.0
Gaussian and Neural Accelerator 3.0 (GNA) technology helps with noise suppression while enhancing background blurring during video chats.

General	CPU Model    Intel Core i7-13700F (13th Gen) CPU Socket    LGA 1700 Manufacturing Process    10 nm Maximum CPU Configuration    1S Maximum Number of PCIe Lanes    16 (Revision 5.0) 4 (Revision 4.0) Unlocked    No
Performance	Number of Cores    16 (8 x P-Cores + 8 x E-Cores) Number of Threads    24 Base Clock Speed    P-Core: 2.1 GHz E-Core: 1.5 GHz Maximum Boost Speed    P-Core Turbo: 5.1 GHz E-Core Turbo: 4.1 GHz L3 Cache    30 MB
Memory Support	Maximum Capacity    128 GB Memory Support    DDR5 Up to 5600 MHz DDR4 Up to 3200 MHz ECC Memory    No Channel Architecture    Dual Channel Maximum Memory Bandwidth    89.6 GB/s Optane Memory Support    Yes
Power	Thermal Design Power (TDP)    65 W Included Thermal Solution    None Maximum Temperature    212°F / 100°C Thermal Monitoring Technologies    Yes
Technology	AES Support    Yes Extension    AVX 2.0, AVX-512, SSE 4.1/4.2 Instruction Set    64-Bit Virtualization    Yes: Intel VT-d, Intel VT-x, Intel VT-x with Extended Page Tables (EPT) DMI    DMI4 (16 GT/s) vPro Support    No Performance Technologies    Deep Learning Boost, Gaussian and Neural Accelerator 3.0, Hyper-Threading, Intel Thread Director, SpeedShift, SpeedStep, Turbo Boost 2.0 Security Technologies    Control-Flow Enforcement (CET), Device Protection with Boot Guard, Execute Disable Bit, MBE (Mode-Based Execute) Control, OS Guard, Secure Key, Software Guard Extensions, Threat Detection Technology (TDT), Trusted Execution Technology Video Technologies    Clear Video, Clear Video HD, InTru 3D, Quick Sync Video
Integrated Graphics	AES Support    Yes Extension    AVX 2.0, AVX-512, SSE 4.1/4.2 Instruction Set    64-Bit Virtualization    Yes: Intel VT-d, Intel VT-x, Intel VT-x with Extended Page Tables (EPT) DMI    DMI4 (16 GT/s) vPro Support    No Performance Technologies    Deep Learning Boost, Gaussian and Neural Accelerator 3.0, Hyper-Threading, Intel Thread Director, SpeedShift, SpeedStep, Turbo Boost 2.0, Turbo Boost Max 3.0 Security Technologies    Control-Flow Enforcement (CET), Device Protection with Boot Guard, Execute Disable Bit, MBE (Mode-Based Execute) Control, OS Guard, Secure Key, Software Guard Extensions, Threat Detection Technology (TDT), Trusted Execution Technology
Packaging Info	Package Weight    1.03 lb Box Dimensions (LxWxH)    5.8 x 4.6 x 3.1"
