Gigabyte AM4 2-DDR4 2 PCIe SVGL MATX
Item #
MBAAM43
Brand
Gigabyte
Model
GA-A320M-S2H

Warranty
3 Year /1 Year OTC /2 Year MFG
Condition
Retail Box
If out of stock
3 to 5 Days
Product Description


GA-A320M-S2H AMD


 Gigabyte Motherboard GA-A320M-S2H AMD Ryzen A320 up to 32GB DDR4 D-Sub/ DVI-D/ HDMI PCI Express Micro-ATX Retail

AMD introduces the latest Ryzen™ 2000 series processors to provide the computing power for budget gaming need. GIGABYTE's full line of AMD AM4 chipset motherboards perfectly fit the latest AMD Ryzen™ 2000 series processors computing performance and integrated graphics output. Users can enjoy the benefits brought by AMD Ryzen™ 2000 series processors by just simply downloading and upgrading the latest BIOS.

 Fast Onboard Storage with NVMe PCIe Gen3 x4 110mm M.2 (Up to 32 Gb/s)
 GIGABYTE M.2 solution offers considerably faster storage performance and support for both PCIe and SATA interfaces* for M.2 SSD devices.

 High Definition Digital Outputs
 Enjoy true HD display capability using the most commonly integrated digital output technologies on today’s HD displays and TVs.

4K Ultra HD Support
4K resolution is the next technological milestone in high-definition content delivery, utilizing approximately 4,000 pixels on the horizontal axis, more than four times today's standard HD pixel density. GIGABYTE motherboards provide native 4K support with integrated AMD Radeon? Graphics via HDMI.



Supports AMD Ryzen™ & 7th Generation A-series/ Athlon™ Processors
Dual Channel Non-ECC Unbuffered DDR4, 2 DIMMs
Ultra-Fast PCIe Gen3 x4 M.2 with PCIe NVMe & SATA mode support
 High Quality Audio Capacitors and Audio Noise Guard
 Realtek® Gigabit LAN with cFosSpeed Internet Accelerator Software
 Smart Fan 5 features 5 Temperature Sensors and 2 Hybrid Fan Headers
 GIGABYTE™ UEFI BIOS
bull; All New GIGABYTE™ APP Center, Simple and Easy Use
APP Center Including Cloud Station™ Utility.

Detail Specifications



CPU
 AM4 Socket: 1.AMD Ryzen processor
2.AMD 7th Generation A-series/ Athlon processor



Chipset
 1.AMD A320



Memory
 1.2 x DDR4 DIMM sockets supporting up to 32 GB of system memory
2.Dual channel memory architecture
3.Support for DDR4 3200(O.C.)/2933(O.C.)/2667/2400/2133 MHz memory modules
 (Actual support may vary by CPU.)
4.Support for ECC Un-buffered DIMM 1Rx8/2Rx8 memory modules (operate in non-ECC mode)
5.Support for non-ECC Un-buffered DIMM 1Rx8/2Rx8/1Rx16 memory modules
6.Support for Extreme Memory Profile (XMP) memory modules



Onboard Graphics
 Integrated Graphics Processor: 1.1 x D-Sub port, supporting a maximum resolution of 1920x1200 at 60 Hz
2.1 x DVI-D port, supporting a maximum resolution of 1920x1200 at 60 Hz
 (The DVI-D port does not support D-Sub connection by adapter.)
3.1 x HDMI port, supporting a maximum resolution of 4096x2160 at 24 Hz
 (Support for HDMI 1.4 version.)
Maximum shared memory of 2 GB



Audio
 1.Realtek ALC887 codec
2 .High Definition Audio
3.2/4/5.1/7.1-channel
4.Support for S/PDIF Out



LAN
 1.Realtek GbE LAN chip (10/100/1000 Mbit)



Expansion Slots
1 x PCI Express x16 slot, running at x16 (PCIEX16)
 ( Actual support may vary by CPU.)
 (The PCIEX16 slot conforms to PCI Express 3.0 standard.)
2 x PCI Express x1 slots (The PCI Express x1 slots conform to PCI Express 2.0 standard.)



Storage Interface
1 x M.2 connector (Socket 3, M key, type 2242/2260/2280/22110 SATA and PCIe x4/x2 SSD support)
 ( Actual support may vary by CPU.)
 ( Supports only M.2 SATA SSDs when using an AMD 7th Generation A-series or Athlon processor.)
4 x SATA 6Gb/s connectors
3.Support for RAID 0, RAID 1, and RAID 10


USB
 Chipset: 1.2 x USB 3.1 Gen 1 ports available through the internal USB header
6 x USB 2.0/1.1 ports (2 ports on the back panel, 4 ports available through the internal USB headers)
CPU: 1.4 x USB 3.1 Gen 1 ports on the back panel



USB
 Chipset: 1.2 x USB 3.1 Gen 1 ports available through the internal USB header
2.6 x USB 2.0/1.1 ports (2 ports on the back panel, 4 ports available through the internal USB headers)
CPU: 1.4 x USB 3.1 Gen 1 ports on the back panel



Internal I/O Connectors
1 x 24-pin ATX main power connector
1 x 8-pin ATX 12V power connector
1 x CPU fan header
1 x system fan header
1 x M.2 Socket 3 connector
4 x SATA 6Gb/s connectors
1 x front panel header
1 x front panel audio header
1 x S/PDIF Out header
1 x USB 3.1 Gen 1 header
2 x USB 2.0/1.1 headers
1 x Trusted Platform Module (TPM) header (2x10 pin, for the GC-TPM2.0 module only)
1 x speaker header
1 x Clear CMOS jumper
1 x chassis intrusion header



Back Panel Connectors
1 x PS/2 keyboard port
1 x PS/2 mouse port
1 x D-Sub port
1 x DVI-D port
1 x HDMI port
4 x USB 3.1 Gen 1 ports
2 x USB 2.0/1.1 ports
1 x RJ-45 port
3 x audio jacks (Line In, Line Out, Mic In)



I/O Controller
 1.iTE I/O Controller Chip



H/W Monitoring
 1.Voltage detection
2.Temperature detection
3.Fan speed detection
4.Overheating warning
5.Fan fail warning
6.Fan speed control



BIOS
 1.1 x 128 Mbit flash
2.Use of licensed AMI UEFI BIOS
3.PnP 1.0a, DMI 2.7, WfM 2.0, SM BIOS 2.7, ACPI 5.0



Unique Features
 1.Support for APP Center
 ( Available applications in APP Center may vary by motherboard model. Supported functions of each application may also vary depending on motherboard specifications.)
 BIOS
 3D OSD
AutoGreen
BIOS Setup
Cloud Station
Color Temperature
EasyTune
Fast Boot
Game Boost
ON/OFF Charge
 Smart Backup
 Smart Keyboard
 Smart TimeLock
System Information Viewer
USB Blocker
 V-Tuner
2.Support for Q-Flash
3.Support for Xpress Install



Bundle Software
 1.Norton Internet Security (OEM version)
2.cFosSpeed



Operating System
1.Support for Windows 10 64-bit
2.Support for Windows 7 64-bit



Form Factor
 1.Micro ATX Form Factor



Item Dimension ( L inch x W inch x H inch)
 11 x 10 x 3



Weight
 2.00 lb



Warranty Information
 3 Years
