EVGA 750WT Single Fan Power Supply

Item #

PS750E

Brand

EVGA

Model

100-N1-0750-L1

Color

Black

Warranty

2 Year

Condition

Retail Box

If out of stock

3 to 5 Days

Add On Products

Fractal Micro ATX Mini Tower No/PS

CS21F

Fractal Micro ATX Mini Tower No/PS usb 3

CS22F

Product Description

EVGA 750 N1, 750W, 2 Year Warranty,

Power Supply 100-N1-0750-L1

When building on a budget, the EVGA 750W power supply is a great choice at a low cost. Supporting 59A on a single +12V rail provides more options without having to reduce your component requirements. The EVGA 750W offers the connections and protections needed for basic system builds. With a standard 2 year warranty and ultra quiet fan design the EVGA 750W power supply will be a great asset for your next build on a budget.

CABLE LENGTH
ATX Cable EPS Cable PCIe Cable SATA Cable Four-Pin Peripheral Cable AC Power Floppy Adapter	1x 550mm 1x 600mm 1x 550mm, 670mm 3x 450mm, 570mm, 690mm 1x 450mm, 570mm, 690mm (Floppy) 1x 1200mm (m) 1x 120mm
CONNECTOR QUANTITY
24 Pin ATX EPS (CPU) PCIe SATA Four-Pin Peripheral Floppy	1x 1x 8pin (4+4) 2x 8pin (6+2) 9x 3x 1x
POWER SPECS
AC Input Rail Max Output Total	110 - 240 VAC, 8-4A, 50 - 60 Hz +3.3V +5V +12V +5Vsb -12V 24A 20A 59A 3A 0.3A 59A 120W 708W 15W 3.6W 750W @ +25C
ADDITIONAL DETAILS
Japanese Capacitors ECO Mode MTBF Net Weight Size Approvals Fan Size / Bearing Operating Temperature	No No 100,000 Hours 4 lbs 86mm (H) x 150mm (W) x 140mm (L) TUV, CB, CE, FCC, RCM, cTUVus, WEEE, RoHS Compliance with ErP Lot 3 2014 Requirement 120mm Sleeve Bearing 0° to 25° C
