EVGA 650WT 80+ Bronze Modular Power

Item #

PS650EV3

Brand

EVGA

Model

220-B5-0650-V1

Color

Black

Warranty

5 Year /2 Year OTC /3 Year MFG

Condition

Retail Box

If out of stock

While Supplies Last

Product Description

Introducing the EVGA B5 power supplies, the latest 80PLUS Certified Bronze power supplies to carry on the EVGA tradition of reliability, performance, and affordability. The B5 power supplies start with the most important standard for reliability - a Japanese main capacitor. Next, the B5 power supplies provide maximum flexibility by using a small chassis and a fully modular design. The ultra-quiet 135mm Fluid-Dynamic Bearing fan becomes silent when coupled with EVGA ECO mode to turn off the fan in medium to low loads. Last, but not least, the B5 power supplies have a full suite of protections and a 5-year limited warranty that you've come to know and expect from EVGA.

80 PLUS Bronze certified, with 89% efficiency or higher under typical loads
Fully Modular to reduce clutter and improve airflow
EVGA ECO Intelligent Thermal Control System eliminates fan noise at low to medium loads
5 Year Warranty and unparalleled EVGA Customer Support
Heavy-duty protections, including OVP, UVP, OCP, OPP, SCP, and OTP

CABLE LENGTH
ATX Cable EPS Cable PCIe Cable SATA Cable Four-Pin Peripheral Cable Floppy Adapter AC Power Modular Cable Type	1x 600mm 1x 600mm 1x 550mm, 1x 550mm, 700mm 2x 500mm, 600mm, 700mm 1x 500mm, 600mm, 700mm 1x Molex to FDD Adapter 1x 1500mm Full
CONNECTOR QUANTITY
24 Pin ATX EPS (CPU) PCIe SATA Four-Pin Peripheral Floppy	1x 24pin (20+4) 1x 8pin (4+4) 3x 8pin (6+2) 6x 3x 1x
INPUT
Input Voltage AC Input Input Frequency Range Efficiency	100-240 VAC 10-5A Range 60/50Hz 85% or Higher Typical
OUTPUT
Rail Max output Total	+3.3V +5V +12V -12V +5Vsb 24A 24A 54.1A 0.5A 3.0A 650W 120W 650W 6W 15W 650W
ADDITIONAL DETAILS
Japanese Capacitors ECO Mode MTBF Net Weight Size Approvals Compliance with Fan Size / Bearing	Japanese Capacitors Main ECO Mode Yes MTBF 100,000 Hours Net Weight 4 lbs Size 85mm (H) x 150mm (W) x 140mm (L) Approvals TUV, CE, FCC, RCM, cTUVus, BSMI, CCC, WEEE, RoHS Compliance with ErP Lot 6 2013 Requirement Fan Size / Bearing 135mm Fluid Dynamic Bearing
