Bytecc 5 Port 10-100 Mini USB PWR ***

Product Description

The smallest 5 port Networking switch series for SOHO & workgroup

Mini switch series feature 5 ports of STP 10 Mbps Ethernet, 100 Mbps fast Ethernet or 10/100Mbps N-Way switch in a single box with mini size. The design of Mini networking Switch Series ingeniously combines the advantage of 5 ports of 10 Mbps STP Ethernet (10 BASE-T), 100 Mbps fast Ethernet (100 BASE-TX), or 10/100Mbps N-Way switch with low cost and high performance, making it the most cost-effective solution to the 10 Mbps or 100 Mbps speed demand.

Mini sized 10 Mbps Ethernet, 10/100 Mbps Auto sensing N-Way Switch.
5 STP (4+1) ports
Dedicate uplink port
Support all major Network Operating Systems (NOS).
LED per port for LINK/ACK status and trouble shooting
Collision LED display
USB power cable is 40 Inches from end to end
Power Supply
External USB POWER CABLE

Power Capacity
+6 Vdc @ 500mA Max.

Operating Temperature
2oC ~ 65oC

Storage Temperature
-30oC ~ 75oC

Humidity
5% ~ 90% non- condensing

Case Material
IRON

Emission Compliance
FCC, CE, BSMI and optional VCCI

Dimension (WxDxH)
82x66x20mm Mini Size
