Video Input / Resolution
|
8 IP Channels up to 8 MegaPixel (4K)
|
|
Main Monitor Output
|
1 x 4K HDMI / 1 x 1080P VGA
|
|
Multi Operation
|
Pentaplex: Live Display / Record / Playback / Backup / Remote Acess
|
|
Recording Compression
|
H.265 / H.264
|
|
OS
|
Embedded Linux
|
|
Recording
|
240fps (30fps per channel)
|
|
Audio over IP Inputs
|
8 (1 Audio Channel per IP Camera over IP)
|
|
Local Audio In/Out
|
IN: RCA x 1CH / OUT: RCA x 1CH
|
|
Two-Way Audio
|
YES
|
|
Encode
|
CBR
|
|
Quality Levels
|
11 level (According to Bit Rate)
|
|
Recording Modes
|
Manual / Timer / Motion / Sensor
|
|
Local Playback
|
8CH
|
|
Search
|
Time sliced image search, Time/Calendar search, Event (Motion, External alarm), Tag search
|
|
Alarm Modes
|
Sensor, Motion, Video loss, IP conflict, Disk error, Illegal access, Network disconnection
|
|
Alarm Inputs
|
IP Camera Dependent (No Local Input)
|
|
Alarm Triggering
|
Record, Snap, PTZ move, Alarm out, E-mail, etc
|
|
Analytics
|
License Plate Recognition, Tripwire, Intrusion, Object Detected/Missing, Exception, Crowd Density, People Counting, Human / Vehicle Classification
|
|
Network Interface
|
RJ45 x 1
|
|
POE ports
|
RJ45 x 8, with POE
|
|
PoE Standard
|
802.3af 15W max per port
|
|
Total PoE Budget
|
100W all ports
|
|
Bit Rate (Per Camera)
|
512Kbps ~ 10 Mbps (Adjustable)
|
|
Total Bandwidth
|
80Mbps Incoming / 80Mbps Outgoing
|
|
Dual-stream
|
Individual Network Video Stream and local recording stream, set separately
|
|
Network Protocols
|
TCP/IP, UDP, DHCP, DNS, PPPOE, DDNS, Email, UPNP, NAT, Telnet
|
|
Internet-streaming
|
Total 33 task resources (Local+Remote) 8 CH IE playback
|
|
Remote Viewing
|
CMS / Web Browser / Mobile Platforms
|
|
Remote Users
|
10 Simultaneous Online Users
|
|
Backup
|
Network, USB
|
|
SATA HDD
|
SATA x 1, max to 10TB each
|
|
PTZ Protocol
|
Through Network
|
|
USB
|
USB 2.0 x 2 (for mouse and USB backup device)
|
|
Power Consumption
|
= 10W (Without HDD), 48V/2.5A
|
|
Weight
|
5.1lbs (2.34kg) |
|
Working Environment
|
32°~122°F @ 10% ~ 90% RH
|
