Image Sensor
|
1/2.7” 5.0 Megapixel Progressive Scan CMOS
|
|
Image Size
|
5 MegaPixel 2592×1944
|
|
Resolution
|
5 MP (2592×1944) / 4 MP (2592×1520) / 3 MP (2304×1296) / 1080P (1920×1080) / 720P (1280×720) / D1/CIF (480×240)
|
|
Min. Illumination
|
0 Lux (IR LED ON)
|
|
Lens
|
2.8mm Fixed Iris Lens
|
|
Day/Night
|
True Day/Night by ICR
|
|
Matrix LED
|
1
|
|
Audio
|
Built-in Mic*
|
|
IR Distance
|
100'
|
|
Video Compression
|
H.265 / H.264 / MJPEG
|
|
Multi-Stream
|
1~20fps: 5 MP, 1~30fps: 4 MP, 3 MP, 1080P, 720P, D1, CIF, 480×240
|
|
WDR
|
Digital Wide Dynamic Range (D-WDR)
|
|
DNR
|
XD-DNR (2D-DNR & 3D-DNR)
|
|
Quality
|
VBR (Five Levels of Adjustment) / CBR (Adjustable)
|
|
Image Setting
|
Saturation, Brightness, Contrast, WDR, Noise reduction
|
|
Built in Features
|
On Board Motion Detection, Privacy Masking, Region of Interest, Exception, Line Crossing, Intrusion, Object Detection / Removal (Museum Search)
|
|
ROI
|
Max 3 detailed areas can be viewed
|
|
Smart Alarm
|
Motion Alarm / Sensor Alarm
|
|
Network
|
RJ45
|
|
Local Storage
|
Built-in micro SD card slot up to 128GB
|
|
Remote Viewing
|
CMS / Web Browser / Mobile (iOS/Android)
|
|
Supported Browsers
|
Internet Explorer, Chrome and Firefox with IE Tab
|
|
Connection Protocol
|
ONVIF
|
|
Weather / Impact Resistance
|
IP67 Weather Resistance
|
|
Power Input
|
12VDC / PoE
|
|
Power Consumption
|
(12VDC) IR On: 120mA / IR Off: 480mA
|
|
Power Consumption
|
(PoE) < 5W
|
|
Working Environment
|
-4~122 / 10%~90% Humidity
|
|
Weight
|
16.58 oz. / 1.03 lbs. / 473g
|
|
Dimensions
|
3.77” x 4.25” (95.7 × 108mm) Dia x H
|
|
|
* Please research local, state, and federal laws regarding the implementation and use of audio surveillance
|
