Camera:
| Sensor:
5 MP 1/2.7" CMOS
Focal Length:
2.8mm
Maximum Aperture:
f/2
Zoom:
Digital: 48x
Lens Field of View:
Horizontal: 103°
Vertical: 76°
Diagonal: 134°
IR Cut Filter:
Mechanical
Day/Night:
Yes
Minimum Illumination:
Color: 0.03 Lux
B&W: 0 Lux
Shutter Speed:
1/32000 to 1/5 Seconds
Camera Angle Adjustment:
Horizontal: 0 to 350°
Vertical: 0 to 75°
|
|
| Video: |
Streaming Resolution:
2560 x 1920 at 20 fps
Supported Video Compression:
H.264, H.265, MJPEG
Multi-View Streaming:
Yes, 3 Streams
|
|
Audio:
|
Built-In Mic:
No
|
|
Pan & Tilt:
|
Pan/Tilt:
No
|
|
| Networking: |
Security:
HTTPS, IEEE 802.1X
Supported Protocols:
ARP, CIFS/SMB, DDNS, DHCP, DNS, FTP, HTTP, ICMP, IGMP, IPv4/v6, NTP, PPPoE, QoS Layer 3 DiffServ, RTCP, RTP, RTSP, SMTP, SNMP v1/v2c/v3 (MIB-II), SSL/TLS, TCP, UDP, UPnP
|
|
System Integration:
|
Application Programming Interface (API):
ONVIF Profiles G & S
Analytics:
Five-Window Video Motion Detection
OS Compatibility:
Windows 7
Windows 8
macOS 10.12
As of March, 2020: Check with the manufacturer for the most up-to-date compatibility
|
|
| Sensors & Alarms: |
Event Trigger:
Yes
Event Action:
Recording, Notification, Alarm
Data Streaming:
Yes
|
|
| Hardware: |
Memory:
512 MB RAM / 128 MB Flash
Media/Memory Card Slot:
Single Slot: microSD/microSDHC/microSDXC [64 GB Maximum]
External Storage Options:
NAS
|
|
Power:
|
Power Source:
PoE 802.3af (15 W)
Power Consumption:
6.49 W
|
|
| Environmental: |
Operating Temperature:
-22 to 140°F / -30 to 60°C
Startup Temperature:
14 to 140°F / -10 to 60°C
Operating Humidity:
90%
IP Rating:
IP66
IK Rating:
IK10
|
|
| General: |
Inputs/Outputs:
1 x RJ45
Illumination:
IR LEDs up to 98.4' / 30 m
Video Management Software:
VAST, Shepherd
Supported Languages:
English, French, German, Italian, Japanese, Portuguese, Simplified Chinese, Spanish, Traditional Chinese
Dimensions:
ø: 4.6 x H: 3.5" / ø: 117.2 x H: 89.6 mm
Weight:
1.19 lb / 540 g
|
|
| Packaging Info: |
Package Weight:
1.78 lb
Box Dimensions (LxWxH):
7.3 x 6.8 x 6"
|
