Image Sensor
|
1/2.7” Progressive Scan CMOS
|
|
| Image Size |
2560 × 1440
|
|
Electronic Shutter
|
1s ~ 1/100000s
|
|
Min. Illumination
|
0.011 lux @F1.2, AGC ON, 0 lux with IR / 0.04 lux @ F2.2, AGC ON, 0 lux with IR
|
|
| Lens |
Fixed 2.8mm @F2.0, Horizontal FoV: 110°, Vertical FoV: 77.6°, Diagonal FOV: 117°
|
|
Lens
|
Mount M12
|
|
| Day & Night |
ICR
|
|
| IRs |
1 Matrix Style IR (up to 100’)
|
|
Wide Dynamic Range
|
Digital Wide Dynamic Range (D-WDR)
|
|
| Other Features |
BLC (Backlight Compensation), HLC (Highlight Compensation), Hardware Reset
|
|
| DNR |
XD-DNR (3D-DNR / 2D-DNR)
|
|
| Video Compression |
(Standard) H.265/ H.264 (H.265 Main Profile @ Level 4.1 High Tier)
|
|
| Bit Rate (Type) |
64Kbps ~ 5Mbps (VBR / CBR)
|
|
| Resolution |
4MP(2560×1440), 3MP(2304×1296), 1080P (1920×1080), 720P (1280×720) D1, CIF, 480×240
|
|
| Main Stream |
60Hz : 4MP/3MP/1080P(1~30fps), 50Hz: 4MP/3MP/1080P(1~25fps)
|
|
Sub Stream
|
60Hz : 720P(1~15fps)/D1 /CIF (1~30fps), 50Hz: 720P(1~12fps)/D1(1~25fps)/CIF (1~25fps)
|
|
Third Stream
|
60Hz : D1/CIF/480×240 (1~30fps), 50Hz: D1/CIF/480×240 (1~25fps)
|
|
| Image Setting |
Saturation, Hue, Brightness, Contrast, Wide Dynamic Range, Sharpness, NR, Adjustable w/ Client Web Browser
|
|
| ROI |
Each ROI to be Configured Separately
|
|
Storage
|
Built-in MicroSD Card Slot, up to 128GB
|
|
| Network |
RJ45
|
|
Remote Monitoring
|
VMS, IE (Plug-in Required), Edge, iOS & Android Apps
|
|
Online Connection
|
Supports Simultaneous Monitoring for up to 4 Users, Supports Multi-stream Real Time Transmission
|
|
| Network Connection |
UDP, IPv4, IPv6, DHCP, NTP, RTSP, RTP, RTCP, ICMP, IGMP, PPPoE, DDNS, SMTP, FTP, 802.1x, UPnP, HTTP, HTTPs, QoS
|
|
| Interface Protocol |
ONVIF
|
|
| Smart Alarm |
Motion Detection, SD Card Full, SD Card Error
|
|
| Programmable Analytics |
Object Removal, Scene Change, Video Blur, Intrusion and Line Crossing
|
|
| General Functions |
Watermark, IP Address Filtering, Video Mask, Operational Diagnostics, Password Protection Protection
|
|
| WiFi Specifications |
IEEE802.11b/g/n, 2.4GHz ~ 2.4835 GHz, 20MHz, WEP, WPA-PSK/WPA2-PSK, 80M Range
|
|
WiFi Transfer Rate
|
11b: 11Mbps, 11g: 54Mbps, 11n: up to 150Mbps
|
|
| Power Supply |
DC12V/PoE
|
|
| Power Consumption |
<5W
|
|
| Operating Environment |
– 30°C ~ 60°C (-22° (-22°F~140°F), Humidity: Less than 95 % (Non Condensing)
|
|
| Dimensions L × W × H |
6.6” × 2.84” × 5.84” (167.6mm × 74.7mm × 148.2mm)
|
|
| Weight Net (Shipping) |
1.03lb / 16.402oz / 465g (1.27lb / 20.29oz / 575g)
|
