Image Sensor:
|
Type: 1/3.0” 4.0 MegaPixel Progressive Scan CMOS
|
|
| Image Specifications: |
Size: 4 MegaPixel (2592×1520)
Resolutions:
4MP (2592×1520)
2K (2560×1440)
3MP (2304×1296)
1080P (1920×1080)
720P (1280×720)
D1, VGA(640×480), CIF, 480×240
|
|
Frame Rate:
|
30fps @ 4MP and lower
|
|
Main Stream:
|
Resolutions: 4MP/2K/3MP/1080P/720P
Frame Rate: 1~30fps (60Hz)
|
|
| Sub Stream: |
Resolutions: 720P/D1/VGA/CIF
Frame Rate: 1~30fps (60Hz)
|
|
Third Stream:
|
Resolutions: D1/VGA/CIF/480×240
Frame Rate: 1~30fps (60Hz)
|
|
| Minimum Illumination: |
0.03lux @ F1.6 with AGC ON, 0 lux with IR, 0 lux with LED
|
|
| Lens: |
Type: 2.8~12mm@F1.4
Horizontal Field of View: 96°~32.33°
Vertical Field of View: 53.67°~19.63°
Diagonal Field of View: 114.17°~36.33°
|
|
Angle Adjustment:
|
Wall Mount: Pan: 0°180°, Tilt: 0°90°, Rotation: 0°~180°
Ceiling Mount: Pan: 0°360°, Tilt: 0°90°, Rotation: 0°~180°
|
|
| Signal-to-Noise Ratio (S/N Ratio): |
=50dB
|
|
| Day/Night Mode: |
True Day/Night by ICR
|
|
| Night Vision/Range: |
White Light or Matrix IR / Up to 130’
|
|
| Video Compression: |
H.265+, H.265, H.264+, H.264, MJPEG [Triple Streaming]
|
|
| Audio Compression: |
G.711A, G.711U
|
|
| Audio: |
1Ch. Audio Input, 1Ch. Audio Output + Built-in Speaker + Built-in Microphone*
|
|
| Alarm: |
1Ch. Alarm Input, 1Ch. Alarm Output
|
|
| Bit Rate/Type: |
64 Kbps ~ 8 Mbps / VBR, CBR
|
|
| Wide Dynamic Range: |
120dB Super WDR
|
|
| Other Features: |
Highlight Compensation, Backlight Compensation, DeFog, Hardware Reset
|
|
| Digital Noise Reduction: |
XD-DNR (3D-DNR & 2D-DNR)
|
|
| Image Setting: |
Various settings including ROI, Saturation, Brightness, Hue, Contrast, Wide Dynamic Range, Sharpness, Image Flip, Image Mirror, Noise Reduction
|
|
| Advanced Analytics: |
Intrusion Detection, Line Crossing, Target Counting [Human/Motor Vehicle Classification], Face Detection, Scene Change, Video Blur, Abnormal Color Detection, Heat Map
|
|
| Smart Alarm: |
Motion Detection, Sensor Alarm, SD Card Error, SD Card Full, IP Address Conflict, Cable Connection
|
|
| Region of Interest (ROI): |
Configurable separately for each ROI
|
|
| Sound/Light Warning: |
Flashing White Lights (Red and Blue) + Speaker with User-Defined Warning Voice Import
|
|
| DORI: |
Detect: 195.73 (59.66m), Observe: 72.28’ (23.86m), Recognize: 39.14’ (11.93m), Identify: 19.55’ (5.96m)
|
|
| Local Storage: |
Built-in MicroSD Card Slot (up to 256GB)
|
|
| Remote Viewing: |
VMS / Web Browser / Mobile (iOS/Android)
|
|
| Online Connection: |
Supports Simultaneous Monitoring for up to 10 Users, Support multi-stream real-time transmission
|
|
| Supported Browsers: |
IE11 (plug-in required), Chrome 89.0+, Edge 89.0+, Firefox 87.0+, Safari 14.0+
|
|
Network Connection:
|
Online Connection:
Supports Simultaneous Monitoring for up to 10 Users, Support multi-stream real-time transmission
Supported Browsers:
IE11 (plug-in required), Chrome 89.0+, Edge 89.0+, Firefox 87.0+, Safari 14.0+
Network Connection:
RJ45 10M/100M Self-Adaptive Ethernet port
Network Protocols:
UDP, IPv4, IPv6, DHCP, NTP, RTSP, RTP, RTCP, PPPoE, DDNS, SMTP, FTP, SNMP, RTMP, HTTP, 802.1x, UPnP, HTTPS, HTTP POST, QoS
Connection Protocol:
ONVIF
|
|
| Security: |
Video Encryption, Firmware Encryption, HTTPs Encryption, Configuration Encryption, Illegal Login Lock, IP Address Filtering, 802.1x Authentication, Basic and Digest Authentication for HTTP/HTTPs
|
|
| PoE: |
Yes, IEEE802.3af
|
|
| Power |
Power Input:
12VDC / PoE
Power Consumption:
PoE: <12W
12VDC: 500mA (LEDs Off) / 1050mA (LEDs On)
|
|
| Weight: & Dimensions: |
Weight:
Net (Gross): 24.0oz / 1.50lb / 680g (29.3oz / 1.83lb / 830g)
Dimensions:
L × W × H: 8.57 × 3.20 × 3.16” (217.8 × 80.5 × 80.3mm)
|
|
| Certificates: |
CE, FCC — Complies with Directive EU RoHS, WEEE(2012/19/EU), Directive 94/62/EC and REACH(EC1907/2006)
*Please research local, state, and federal law regarding the implementation and use of audio surveillance
|
