Video Input / Resolution
|
4 IP Channels up to 6 MegaPixel 6MP/5MP/4MP/3MP/1080P/1280×1024/960P/720P/960H/D1/CIF
|
|
Main Monitor Output
|
HDMI × 1: 1920 × 1080 / 1280 × 1024 / 1024 × 768 VGA × 1: 1920 × 1080 / 1280 × 1024 / 1024 × 768
|
|
Multi Operation
|
Pentaplex: Live Disp./Record/Playback/Backup/Remote Access
|
|
Recording Compression
|
H.265S / H.265+ / H.265 / H.264
|
|
OS
|
Embedded Linux
|
|
Recording [Frame Rate]
|
5MP@120fps, 4MP/3MP/1080P/1280×1024/960P/720P/ 960H/D1/CIF@120fps [30fps/ch.], 6MP@80fps
|
|
Audio
|
4 Channel IPC Audio Input (Supported via HDMI)
|
|
Audio Compression
|
G.711(U/A)
|
|
Recording Stream
|
Dual Stream Recording
|
|
Recording Modes
|
Manual / Timer / Motion / Sensor / Analytics
|
|
Simultaneous Playback
|
Max. 4 Ch.
|
|
Playback Search
|
Time Slice / Time / Event / Tag Search / Smart Search
|
|
Smart Search
|
Highlighted Color Displays the Recording in a Certain Time Period, Different Colors Refer to Dif. Events
|
|
Playback Function
|
Play, Pause, Fast Forward / Back, Digital Zoom, Smart Events
|
|
Alarm Modes
|
Manual, Sensor, Motion, Exception, Smart Events
|
|
Alarm Linkage
|
Record, PTZ, Cruise, Alarm Out, Pop-up Window, Email, Buzzer, App Push
|
|
Alarm Input / Output
|
Supports IP Camera Input / Output
|
|
Alarm Triggering
|
Record, Snapshot, Buzzer, Preset, E-mail
|
|
VCA (Video Content Analytics)
|
Object Missing, Region Intrusion, Tripwire, Exception
|
|
License Plate Recognition
|
YES
|
|
POS Information Overlay
|
YES – On Live View and Playback
|
|
Decoding
|
Live View / Playback – 1 Ch. 6MP / 4 Ch. 720P
|
|
Network Protocol
|
DHCP, DNS, PPPoE
|
|
Network Bandwidth
|
28Mbps Incoming / 28Mbps Outgoing
|
|
PoE Standard
|
IEEE802.3af
|
|
PoE Port
|
RJ45 100M × 4
|
|
Mobile Device
|
iOS, Android
|
|
SATA HDD Storage
|
SATA2.0/3.0 × 1 (Max 10TB)
|
|
Network Backup
|
YES
|
|
Local Backup
|
U Disk, USB Mobile HDD
|
|
USB
|
USB 2.0 × 2 (Rear)
|
|
Remote Control
|
Optional
|
|
Power Consumption / Supply
|
< 6W (Without HDD) / DC 48V / 1.25A
|
|
PoE Output Power
|
= 40W
|
|
Working Environment
|
14°~122°F @ 10% ~ 90% RH
|
|
Dimensions (W × D × H)
|
10.04 × 8.74 × 1.66” / 255 × 222 × 42mm
|
