Video
|
Video Compression H.265, H264, MJPEG
Maximum Frame Rate 30 fps @ 1920x1080
Maximum Streams 3 simultaneous streams
S/N Ratio 66 dB
Dynamic Range 120 dB
Video Streaming Adjustable resolution, quality and bitrate, Smart Stream III
Image Settings Time stamp, text overlay, flip & mirror; Configurable brightness, contrast, saturation, sharpness, white balance, exposure control, gain, backlight compensation, privacy masks; Scheduled profile settings, 3DNR, video rotation, defog
|
|
| Audio |
Audio Capability One-way Audio
Audio Compression G.711, G.726
Audio Interface Built-in microphone, External line in
Effective Range 5 meters
|
|
Network
|
Users Live viewing for up to 10 clients
Protocols 802.1X, ARP, CIFS/SMB, CoS, DDNS, DHCP, DNS, FTP, HTTP, HTTPS, ICMP, IGMP, IPv4, IPv6, NTP, PPPoE, QoS, RTSP/RTP/RTCP, SMTP, SNMP, SSL, TCP/IP, TLS, UDP, UPnP
Interface 10 Base-T/100 Base-TX Ethernet (RJ-45)
ONVIF Supported
|
|
Solution Integration
|
Video Motion Detection Five-window video motion detection
VADP Package Trend Micro IoT Security, Stratocast, VIVOCloud
|
|
| Alarm and Event |
Alarm Triggers Motion detection, manual trigger, digital input, periodical trigger, system boot, recording notification, camera tampering detection, audio detection, SD card life expectancy, cybersecurity events (brute force attack event, cyberattack event, quarantine event)
Alarm Events Event notification via digital output, email, HTTP, FTP, NAS server, SD card, File upload via email, HTTP, FTP, NAS server, SD card
|
|
General
|
Connectors RJ-45 cable connector for 10/100Mbps Network/PoE connection*1, Audio input*1, Digital input*1 (30V, 1A), Digital output*1 (12V, 50mA)
LED Indicator System power and status indicator
Power Input IEEE 802.3af PoE Class 2
Power Consumption Max. 5.5 W (IR on), Max. 2.8 W (IR off)
Dimensions 98 x 54 x 110.8 mm
Weight 400 g
Casing IP66, IP67, IK10, NEMA 4X
Safety Certifications CE, LVD, FCC Class B, VCCI, C-Tick, UL
Starting Temperature: -25°C ~ 55°C (-13°F~ 131°F)
Working Temperature: -25°C ~ 60°C (-13°F~ 140°F) (IR off), -25°C ~ 55°C (-13°F~ 131°F) (IR on)
Humidity 98%
Warranty 24 months
|
