Video Input / Resolution
|
6 IP Channels up to 8 MegaPixel [4K] 8/6/5/4/3MP/1080P/1280×1024/960P/720P/960H/D1/CIF
|
|
Main Monitor Output
|
HDMI × 1: 3840 × 2160 / 1920 × 1080 / 1280 × 1024 / 1024 × 768 VGA × 1: 1920 × 1080 / 1280 × 1024 / 1024 × 760
|
|
Multi Operation Pentaplex:
|
Live Disp./Record/Playback/Backup/Remote Access
|
|
Recording Compression
|
H.265S / H.265+ / H.265 / H.264
|
|
OS
|
Embedded Linux
|
|
Recording
|
8/6/5/4/3MP/1080P/1280×1024/960P/720P/960H/D1/CIF@480fps
|
|
Audio
|
16 Ch. IPC Audio In., 2-Way: 1 × RCA, Local O/P: 1 × RCA
|
|
Audio Compression
|
G.711(U/A)
|
|
Recording Stream
|
Dual Stream Recording
|
|
Recording Modes
|
Manual, Timer, Motion, Sensor, Analytics
|
|
Decoding:
|
Live View / Playback 1Ch. 8MP / 4Ch. 1080P
|
|
Simultaneous Playback
|
Max. 16 Ch.
|
|
Playback Search
|
Time Slice / Time / Event / Tag Search / Smart Search
|
|
Smart Search
|
Highlighted Color Displays the Recording in a Certain Time Period, Different Colors Refer to Dif. Events
|
|
Playback Function
|
Play, Pause, Fast Forward / Back, Digital Zoom, Smart Events
|
|
Alarm Modes
|
Manual, Sensor, Motion, Exception, Smart Events
|
|
Alarm Linkage
|
Record, PTZ, Cruise, Alarm out, Pop-up Window, Email, Buzzer, App Push
|
|
Alarm Input / Output
|
Supports IP Camera Input / Output
|
|
Alarm Triggering
|
Record, Snapshot, Buzzer, Preset, E-mail
|
|
VCA (Video Content Analytics)
|
Object Missing, Region Intrusion, Tripwire, Exception
|
|
License Plate Recognition
|
YES
|
|
POS Information Overlay
|
YES – On Live View and Playback
|
|
Network Protocol
|
DHCP, DNS, PPPoE
|
|
Network Bandwidth
|
112Mbps Incoming / 112Mbps Outgoing
|
|
PoE Standard
|
IEEE802.3af
|
|
PoE Port
|
RJ45 100M × 16
|
|
Mobile Device iOS
|
Android
|
|
SATA HDD Storage
|
SATA2.0/3.0 × 2 (Max 20TB)
|
|
Backup (Network) / Local
|
YES / U Disk, USB Mobile HDD
|
|
| USB |
USB 2.0 × 2 (1 Front + 1 Rear)
|
|
Remote Control
|
Optional
|
|
Power Consumption / Supply
|
< 15W (Without HDD) / DC 48V / 4A
|
|
PoE Output Power
|
= 150W
|
|
Working Environment
|
14°~122°F @ 10% ~ 90% RH
|
|
Dimensions (W × D × H)
|
14.96 × 10.55 × 1.77” / 380 × 268 × 45mm
|
|
Weight (Net / Gross)
|
3.92 / 7.94lbs (1.78 / 3.6kg)
|
